COMP Cams
Comp Cams Ford 4.6L 4 Valve Beehive Spring
Comp Cams Ford 4.6L 4 Valve Beehive Spring
Couldn't load pickup availability
- Ships direct from the brand or supplier
- Tracking emailed when it ships
- Free fitment check before you order
Listed for: Ford 4.6L 4Fitment notes & questions
COMP Cams Valve Springs By Usage
PERFORMANCE STREET
- Unique spring design reduces weight while providing better valve control and maintaining stability of performance street applications
- Increased harmonic resistance increases stability and reduces damaging harmonics
- Oval/multi-arc shape places maximum surface area at the point of highest stress
- Revolutionary design yields more stability, higher RPM and more horsepower
COMP Cams Beehive Valve Springs are revolutionizing performance street applications. With the valve control and reduced weight that Beehive Springs deliver, street cars are now able to turn more RPM and have higher lift camshafts while maintaining the stability of OE applications. The unique Beehive design reduces spring and retainer weight even as it yields greater spring stability. In addition, the oval shape of the wire allows better heat dissipation for longer spring life.
O.D.: .943 (Top) 1.105 (Bottom)
I.D.: .580 (Top) .742 (Bottom)
Seat Load: 90 @ 1.470
Open Load: 252 @ .970
Coil Bind: 0.900
Rate (Lbs./In.): 324
Titanium Retainer: 798
Steel Retainer: 799
Cup Seat: N/A
Shims: N/A
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1997 | Ford | Mustang | Cobra |
| 1998 - 2003 | Ford | Mustang | Equipado |
| 2001 | Ford | Mustang | GT Bullitt |
| 2004 | Ford | Mustang | GT Equipado, GT Base |
| 1996 - 1997 | Ford | Mustang | High |
| 2003 - 2004 | Ford | Mustang | Mach 1 |
| 1998 | Ford | Mustang | Semi-Equipado |
| 2003 | Ford | Mustang | SVT Cobra 10th Anniversary |
| 2000 | Ford | Mustang | SVT Cobra R |
| 1996 - 2004 | Ford | Mustang | SVT Cobra, GT, Base |
| 1996 | Lincoln | Continental | Anniversary |
| 1997 - 2002 | Lincoln | Continental | Base |
| 1995 | Lincoln | Continental | Signature, Diamond Anniversary |
| 1995 - 1997 | Lincoln | Continental | Spinnaker Edition |
| 1996 | Lincoln | Mark VIII | Anniversary |
| 1993 - 1998 | Lincoln | Mark VIII | Base |
| 1995 - 1998 | Lincoln | Mark VIII | LSC |
| 2003 - 2004 | Mercury | Marauder | Base |
